Pneumatic American Type Wooden Pallet Nailing Table

  • Pneumatic pallet nailing table station is an efficient and stable manual wooden pallet production equipment, which is widely used in the production of European and American standard pallets.

Introduction

Pneumatic pallet nailing table station is an efficient and stable manual wooden pallet production equipment, which is widely used in the production of European and American standard pallets.

Pneumatic pallet nailing table adopts pneumatic power and is suitable for the automated nailing operation of wooden pallets. The equipment has the characteristics of fast nailing speed, accurate nailing position and simple operation, which can significantly improve production efficiency and reduce labor costs.

Pneumatic power: The equipment adopts pneumatic system, stable operation, uniform nailing force, and ensures the firmness of nails.

Manual operation: manual nailing and manual feeding, suitable for single-person operation.

Versatility: It is suitable for a variety of pallet specifications (such as European standard and American standard), and the nailing depth and nailing distance can be adjusted according to needs to adapt to different production needs.

High stability: The equipment is reinforced with high-strength screws, with a stable structure, not easy to deform, and a long service life.

Humanized design: The equipment is easy to maintain and equipped with an automatic lubrication system to reduce the frequency of manual maintenance.

Parameters
Model PT-1700
Wood pallet length 600-1300mm
Wood pallet width 800-1700mm
Operational mode Pneumatic operation
Air pressure 0.8MPA
Production efficiency 30-40pcs /h
Number of beams 4p (or customized)
Number of nail guns 1P (CN70)
Weight 440kg
Size 2250*980*1900mm
Applications

Pneumatic pallet nailing table is widely used in the production of European and American standard pallets. It supports a variety of specifications and models. The equipment has low operating costs and can effectively reduce the cost of pallet production.
