Farm Agricultural Tractor

  • Farm tractor is indispensable power machinery in agricultural production. They are mainly used to pull and drive various agricultural machinery and implements to complete operations such as plowing, sowing, fertilizing, and harvesting. They are designed to improve agricultural production efficiency and reduce labor intensity.

Introduction

Farm tractor is indispensable power machinery in agricultural production. They are mainly used to pull and drive various agricultural machinery and implements to complete operations such as plowing, sowing, fertilizing, and harvesting. They are designed to improve agricultural production efficiency and reduce labor intensity.



Farm tractor main functions:

Traction function: It can pull agricultural machinery such as plows, harrows, and seeders.

Driving function: It drives harvesters, sprayers, and other equipment through the power output shaft.

Hydraulic function: It is equipped with a hydraulic system for lifting and controlling agricultural machinery and implements.



Farm tractor dvantages:

High efficiency and energy saving: It adopts advanced engine technology, has low fuel consumption and low emissions.

Easy operation: It is humanized in design, comfortable to drive, and easy to operate.

Strong durability: It adopts high-quality materials, has a solid structure, and has a long service life.

Versatility: It can be equipped with a variety of agricultural machinery and implements to meet various operating needs

Parameters

100HP Farm Tractor



Dimensions of tractor Type / Drive type (4×4)
Power kW 74
Dimension(L×W×H) mm 3945×1860×2730
Wheel base mm 2110
Min.ground clearance mm 360
Min.Weight kg 3050
Tread mm Front tread:1400
Rear tread:1400
Power Clutch / Dry-type,double-acting
Engine / (Ⅱ) 4 Cylinder
Rated speed r/min 2400
Working part Gear / 12F+12R
PTO Type / 8 Spline、Φ38、Ⅰtype(Option: 6 Spline)
PTO Rated power kW ≥63
PTO Speed r/min 540/720 or 540/1000
Hydraulic system Three point linkage / Rear,three-point suspension,cat 2
Hydrualic output / 2-Way valve
Hydrualic adjustment type / Forced hydrualic system,position control,floating control
Max.lifting force at frame center kN ≥20.2
Tyre Tyre (Front/ Rear) / 8.3-24/14.9-30
Note:We also have 25HP, 30HP, 40HP, 50HP, 60HP, 70HP, 80HP, 90HP, 110-150HP,160-200HP tractor.
Applications

As a multifunctional agricultural machinery, farm tractor is widely used in multiple agricultural production links. The following are their main application areas:



1. Cultivation

Tillage: Use plows to till the soil, improve soil structure and increase air permeability.

Deep loosening: Use deep loosening machines to loosen deep soil and promote root growth.

2. Sowing and fertilization

Sowing: Use traction seeders for precise sowing to improve sowing efficiency.

Fertilization: Use fertilizer machines to fertilize the soil to ensure crop nutrient supply.

3. Field management

Cultivation and weeding: Use cultivators to weed and loosen the soil to reduce weed competition.

Spraying: Use traction sprayers to spray pesticides to prevent and control pests and diseases.

4. Irrigation operations

Tow irrigation equipment: Such as sprinklers and drip irrigation equipment for efficient irrigation.

5. Harvesting operations

Harvesting: Use traction combine harvesters to harvest crops and improve harvesting efficiency.

Transportation: Equipped with trailers for crop transportation to reduce manual handling.

6. Orchard and Gardening

Pruning: Use special equipment to prune fruit trees to promote healthy growth of fruit trees.

Picking: Use a tractor to pick fruits to improve picking efficiency.

7. Special terrain operations

Wetland operations: Crawler tractors are suitable for wetland operations to reduce damage to the soil.

Slope operations: Tractors equipped with anti-skid devices are suitable for slope operations to ensure safety.

8. Animal Husbandry

Feed mixing: Use a feed mixer to mix feed to improve feed utilization.

Feces cleaning: Use a dung cleaner to clean feces to keep the breeding environment clean.

9. Forestry operations

Timber transportation: Use a timber transporter to transport timber to improve transportation efficiency.

Forest land cleaning: Use special equipment to clean forest land to promote tree growth.

10. Infrastructure construction

Land leveling: Use a grader to level the land to prepare for infrastructure construction.

Road construction: Use a roller to build roads to improve road quality.
